The market pays only plants
that keep their promises.

The power to keep a promise comes from the power to protect the field. HaemilSoft Co., Ltd. built that power guarding 198 ESS plants, and built the ENERBOT Energy Platform on top of it.

Protecting

Accidents almost happen every day

Follow one ESS plant through 24 hours. Pick a time to see what happens then, and how the common way and ENERBOT part ways.

00:0003:0006:0009:0012:0015:0018:0021:0024:00
11:20
When a cloud passes

A passing cloud does not pull power from the grid

Solar output shifts more than ten thousand times a day. Only when commands go out on change, not on a timer, does the battery stop pulling the shortfall from the grid.

If it still pulls, a red row appears; after 30 seconds in a row (or 60 seconds within 5 minutes) charging stops.

Common way
  1. 10-second timer
  2. Up to 13 s late
  3. 456 kW command held
  4. 216 kW pulled from the grid
ENERBOT
  1. Read every 0.2 s
  2. Sent on change
  3. 228 kW within 0.4 s
  4. Zero grid pull
Does the command follow PV? (kW, 60 s)PV outputCommon timer commandENERBOT command
01002003004005000s10s20s30s40s50s60sPulled from grid

Illustrative example. While the orange line is above the yellow one, the battery charges from the grid.

A reconstruction for explanation. The times are made up, but every scene actually happened in the field.

198ESS plants built by HaemilSoft Co., Ltd.
0.2sPCS · battery · PV read cycle (field-measured 0.24–0.36 s)
0.4sFor the command to follow a change in solar
1minFrom a silent field to the person on call

The answer to each of the six scenes came from 198 sites.In the next part, this power becomes the power to keep market promises.

See a plant’s whole day

Promising

From a market that builds and sells, to one that aggregates, promises and delivers

As renewables strain the grid, the government and grid operators have started giving the work to operators who aggregate scattered resources, promise in advance, and keep that promise.

Solar curtailment days in Honam (days / year)
28220232025

Days when generation stopped because the grid could not take the surplus. Same report: Honam is 62.8 % of the 3,939 MW waiting for grid connection. Source: Maeil Ilbo, 2026-07-12

Until now

Build plants one by one, sell what they make

  • Nobody asks when or how much
  • Running is enough

From now on

Aggregate resources and promise how many kW at what hour tomorrow

  • Keep it and get paid; miss it and lose
  • Only operators who can keep promises remain
Know preciselyForecast tomorrow, and know the present every 0.2 s
Move on timeAct on orders at once, with protection first
Hold when cut offRun the confirmed plan if the link drops; keep the record

Each scheme makes a different promise, and a different party pays

SchemeWhat is promisedWho pays · whatENERBOT
KEPCO DSO linkTomorrow’s hourly export plan · follow KEPCO ordersKEPCO · registered VPP systemPreparing grid testsVPP operators
└ Feeder flexibilityMore / less export on this feeder at this hourKEPCO · metered kWh × bid − shortfall (planned 2027)Preparing grid testsVPP operators
KPX forecast schemeTomorrow’s hourly generationPower exchange · KRW 4 within 4 %, KRW 3 within 6 % / kWhTrial operationForecasting
KPX dispatchStay under the instructed output capPower exchange · settled by scheme rulesTrial operationVPP operators
Solar income villagesRun village solar and a shared ESSPower sales · grid services (set by the call)In talksSolar villages
Heating electrificationControl · communication · data sharing · next-year reportSubsidy · KRW 2 million per home for control and commsIn developmentHeat pumps
Peak-cut · FEMS · BEMSCut peak demand and usageCustomer · lower electricity billsIn developmentFactories · buildings

One plant can take part in several schemes. Status words match All business areas.

When promises overlap, a set order decides

  1. 1ProtectionBattery · fire · climate · always first
  2. 2Grid operator ordersKEPCO curtailment · adjustment
  3. 3Real-time confirmedHours re-set by 15-minute bids
  4. 4Day-ahead confirmedYesterday’s approved hourly plan
  5. 5ScheduleThe plant’s base charge/discharge timetable

No order can override protection.If the link drops, the plant runs the confirmed plan; if the server drops, the ESS stops. This is where part 1’s protecting power is used.

Promises are made in the market, but kept in the field.That is why one company built everything from the field RTU to the KEPCO link as one.

Solutions at a glance

One platform

Five steps from the field to the market, built as one

The middle four are ENERBOT. Even after the sale, the company that built it runs it.

Field

Field equipment

Batteries · PCS · inverters · meters · HVAC · fire · heat pumps

1ENERBOT

Field RTU

Read every 0.2 s · protection · commands · stop when cut off · keep records

2ENERBOT

Encrypted VPN

A separate link per plant · a key per plant

3ENERBOT

EMS server

Storage · decisions · alerts · history · trends · reports · KESCO

4ENERBOT

VPP operator system

Portfolios · forecasts · bids · KEPCO · forecast scheme · dispatch

Linked to

KEPCO · power exchange

Orders · bids · forecast submission · settlement

How it differs from common remote monitoring

Common wayENERBOT
CommandsSent on a timer · up to 13 s lateSent on change · 0.4 s
Device failureWhole plant stopsRuns without the failed unit · auto reset
Unknown stateLast value shown as normalSeparates not installed / not collected / disconnected / unknown, safe side
Line downRecords lost meanwhileStop · 1-minute alert · 7 days on the RTU, then filled in
AlertsA flood, one per plantOur-side problems in one alert · tap to the row
MarketWatch onlyKEPCO link · bids · forecast scoring · dispatch judging
Promise mathsCalculated apart from the fieldSame settings and order as the field EMS · only what can be kept

“Common way” is not a specific product, but what we often saw in the field.

ESS dashboard · operating conditions and equipment
ESS dashboard · operating conditions and equipment
VPP dashboard · plan and KEPCO link
VPP dashboard · plan and KEPCO link
Phone
Phone

Real ENERBOT screens (Korean UI) · development test environment · plant names and addresses hidden

On the same platform, there are three ways to work together.

ENERBOT platform

Working together

Three paths, and whichever you take, the maker runs it with you

Power producers

Run ESS and solar plants safely

  • ESS EMS · solar monitoring · integrated control
  • Field RTU · VPN · phone alerts
  • KESCO operating data
Power producers
Partner VPP operators

A system for companies starting VPP

  • VPP operator system provided
  • Keys, portfolios and screens per operator
  • Operated with HaemilSoft
Partnership
HaemilSoft directly

HaemilSoft as the operator

  • Plant resources aggregated
  • KEPCO and exchange schemes
  • Revenue shared by contract
VPP operators
  1. 1TalkPlant · business · schedule
  2. 2Site checkEquipment · protocols · line
  3. 3RTU · VPNA key issued per plant
  4. 4Register · testComms and protection per device
  5. 5Go liveOperated with HaemilSoft

From Ulsan’s industrial sites to an energy platform

One rule learned in the field has carried us for eleven years: a plant must never run on what it does not know.

2015 ~ 2017

Industrial sites

Quality and supply-chain systems for automotive, shipbuilding and petrochemicals

Miss a single record and it becomes a defect

2016 ~ 2018

Into energy

EoT Convergence R&D Center · solar PMS · ESS monitoring cloud

When communication drops, stop and alert

2018 ~

198 sites

ESS plants across Korea, from 300 kWh to 9 MWh

A plant must never run on what it does not know

2019

Abroad

Wind-linked microgrid in Mongolia · EMS supply agreements in China and Germany

The EMS became multilingual

2020 ~ 2024

Research · pilots

Grid stabilisation · hybrid ESS · DC power trading · FEMS

We tried the next technologies first as projects

2025 ~

Platform

V3.0 engine · ENERBOT Energy Platform

We rebuilt everything we learned from the ground up

Plants built by battery capacity (total 198)
up to 300 kWh108
up to 1.5 MWh34
up to 3 MWh37
up to 9 MWh19

Source: Projects (2026-11)

Where we are going, in four steps · each step stands on the one below

An EMS that protects

Supplying

A VPP that promises

Trial operation · Preparing grid tests

Toward demand

In development

Toward villages and regions

In talks
